900LBS BW Forged steel Swing check Valve

Design standard: API 602.

Body material: A105N

Nominal diameter: 4”

Pressure: CL900LBS

End connection: Butt Welded SCH160

Face to face: ASME B16.10.

Working temperature: -29℃~+425℃..

Test and inspection: API 598.

PSB Design valve

Full bore Check Valve

Graphite stem packing

On Request

Available Material: A105, A350LF2, Stainless steel, Alloy steel.

Optional Stem: A182F6a, A182F304, A182F316, F51/F53

Optional Seat & Trim: STL, Stainless steel, SDSS

Optional End connection: Butt Welded ANSI B16.25

Socket welding: ANSI B16.11

Screw ends: ANSI B1.20.1

Flanges ANSI B16.9

Range of valve sizes diameter: 1/2″~4″ (DN15~DN100).

Range of pressure: 150lbs~2500lbs (PN16~PN420).

 Performance & Functions

When the medium flows in the specified direction, the valve disc is opened by the force of the medium; when the medium is countercurrent, the valve disc is tightly sealed with the valve seat due to the weight of the valve disc and the reverse force of the medium. Closed together to achieve the purpose of preventing the medium from flowing back.

Application:

The medium is water, steam, gas, corrosive medium, oil, medicine, etc.

Suitable for clean media, not suitable for media with solid particles and high viscosity.
